Pallet Racking System Manufacturer
Our Pallet racking system offer multi-level industrial storage structure engineered to store palletized goods in warehouses, DCs, and factories.
HEDA Shelves manufactures racking system from selective to automated shuttle. Buy HEDA SHELVES pallet racking with CE-CPR certified, factory-direct, rich experience in warehouse rack custom. Heavy duty load rated up to 4,500 kg/level standard; higher capacities available on request.
Full OEM Product Range
6 Pallet Racking System Types
Each system type engineered for specific storage density, access patterns, and operational workflows. All available for OEM/ODM manufacturing — custom dimensions, RAL colors, and private labeling.
Selective Pallet Racking
100% direct forklift access to every pallet. The most versatile pallet racking system for high-SKU warehouses. Adjustable beam heights accommodate mixed pallet sizes.
Drive-In Racking
Eliminate aisles entirely. Store 75–80% more pallets in the same footprint. Ideal for cold storage, food distribution, and bulk homogeneous goods with LIFO rotation.
Double Deep Racking
Two pallets deep per bay increases storage density 30–40% vs selective racking. Requires a double-deep reach truck. Best for medium-SKU operations.
Narrow Aisle (VNA) Racking
Reduce aisle width to 1.5–1.8 m while maintaining 100% pallet selectivity. Combines high density with full access. Requires turret truck or articulated forklift.
Radio Shuttle Racking
Remote-controlled carrier moves pallets inside the rack lane. Reduces forklift travel time by 60%. FIFO/LIFO modes. 2-way and 4-way shuttle configurations available.
Pallet Live / Carton Flow
Gravity-fed roller lanes rotate stock automatically. FIFO guaranteed with no operator intervention. Separate loading and picking aisles prevent traffic conflict.
Technical Specifications
Standard Spec Range
All parameters are fully customizable for OEM orders. Free AutoCAD 3D drawings and structural load calculations provided before production begins.
Selective Pallet Racking — Q235B Cold-Rolled Steel · Up to 4,500 kg/level
Electrostatic Powder Coated · Custom RAL Colors Available
| Parameter | Standard Range | Custom Option |
|---|---|---|
| Upright Height | 1,500 – 12,000 mm | Up to 15,000 mm |
| Upright Depth | 600 – 1,200 mm | Custom to pallet |
| Beam Length | 1,800 – 4,000 mm | Custom width |
| Max Beam Capacity | Up to 4,500 kg/level | Higher on request |
| Frame Load Capacity | 10,000 – 30,000 kg | Per engineering calc |
| Steel Grade | Q235B Cold-Rolled Steel | Higher grade avail. |
| Upright Thickness | 1.5 – 2.5 mm | Up to 3.0 mm |
| Beam Profile | Step beam / Box beam | Custom section |
| Surface Treatment | Acid wash + Phosphate + Powder Coat | Hot-dip galvanized |
| Standard Colors | Orange uprights / Blue beams | Any RAL code |
| Hole Pattern Pitch | 50 mm / 75 mm teardrop | Custom |
| MOQ | Flexible — from 1 set | OEM: discuss BOM |
| Lead Time | 15–25 working days | 25–40 days (large) |
| Certifications | CE-CPR · ISO 9001:2015 · RoHS | Docs with shipment |
| Shipping Terms | FOB Guangzhou | CIF on request |
Free structural calculation report with every order. Higher beam capacities beyond 4,500 kg/level available through custom engineering — contact our team.
Q235B Cold-Rolled Steel — Why It Matters
HEDA uses Q235B cold-rolled steel (equivalent to ASTM A36 / S235 EN standard) for all standard uprights and beams. All components undergo 4-step treatment: acid washing → zinc phosphating → primer coat → electrostatic powder coat (80–100µm), providing robust corrosion protection for long-term warehouse use.
Why Choose HEDA Shelves
Racking System Factory Works
25 years manufacturing pallet racking systems for warehouse managers, distribution center operators, and project distributors worldwide. Factory-direct. No middlemen.
HEDA engineers deliver free AutoCAD 3D layouts and load calculations for every project — warehouse managers receive a full storage plan within 24–48h.
Full certification documentation shipped with every order. All steel treated with acid washing, phosphating, and electrostatic powder coating for robust long-term corrosion protection.
Custom dimensions, any RAL color, private labeling. Our engineering team handles drawing approval, production, and export packaging from MOQ 1 set.
No minimum order constraint. Standard orders ship in 15–25 working days from our automated Guangdong production lines with 15,000 sets/month capacity.
Zero distributor markup. Transparent FOB Guangzhou pricing for project distributors and direct warehouse buyers. CIF available on request.
Every distribution center or warehouse project is assigned a bilingual account manager handling design approvals, production tracking, and after-sale support.
All rack components rated for –30°C to +40°C operating range. Hot-dip galvanized finish available for freezer and coastal environments.
Proven export logistics to 120+ countries. Full export documentation: CE declaration, mill certificates, packing lists, and customs HS codes included.
From initial warehouse layout design to manufacturing, quality inspection, and export — HEDA handles every step. One partner, one contact, zero coordination overhead.
Quality Assurance
Certified to Global Standards
HEDA Shelves' pallet racking systems carry three internationally recognized certifications — CE-CPR, ISO 9001:2015, and RoHS. Full certification documents are provided with every shipment, enabling smooth customs clearance and compliance in all major markets.
Construction Products Regulation (CPR) conformity — confirms HEDA pallet racking meets EU structural safety requirements for warehouse and industrial use. Mandatory for all EU market sales.
CE marking for warehouse pallet racking systems. Verified structural performance under EN 15512 loading and stability standards. Covers all HEDA selective, drive-in, and shuttle racking products.
Internationally recognized quality management certification covering HEDA's full manufacturing process — design, raw material sourcing, production, QC inspection, and delivery. Audited by independent third-party body.
RoHS Compliance — Restriction of Hazardous Substances
All HEDA pallet racking surface coatings and finishes comply with EU RoHS Directive (2011/65/EU), restricting the use of hazardous substances including lead, mercury, cadmium, and hexavalent chromium. RoHS compliance documentation available upon request. Full certification package (CE-CPR + ISO 9001:2015 + RoHS declarations) is provided with every shipment at no additional charge.
Industry Applications
Pallet Racking Solutions by Industry
HEDA designs industry-specific pallet racking solutions that account for load types, access requirements, temperature conditions, and operational safety standards. One-stop solution for every sector.
3PL / Logistics
High-throughput selective systems with optimized pick-path aisle layouts for fast-moving e-commerce, parcel, and distribution operations. Warehouse project distributors rely on HEDA for scalable one-stop storage solutions.
Cold Storage
Cold environments demand density to minimize energy costs. Drive-in and radio shuttle systems reduce door-opening frequency by up to 60%. All steel rated for –30°C to +40°C. Galvanized finish available.
Manufacturing
Heavy raw materials and finished goods stored adjacent to production lines. Q235B cold-rolled steel beams support up to 4,500 kg/level (customizable higher) for steel coils, automotive parts, and industrial components.
E-Commerce / Retail
High-SKU operations with fast order cycling. Selective racking in multi-level pick configurations or mezzanine floors maximize vertical space. Distribution center managers choose HEDA for rapid deployment and flexible MOQ.
Agriculture / FMCG
Seasonal bulk storage with strict FIFO requirements. Pallet live racking (gravity flow) automates stock rotation — first in, first out — with zero operator intervention. Ideal for grains, beverages, and packaged goods.
Construction
Long-length materials — timber, pipe, steel bar, sheet metal — need open-bay storage. Cantilever racking provides front-column-free storage for variable-length goods up to 12 m. Heavy-duty selective for bagged materials.
Factory Production Process
From Steel to Installed — 6 Steps
Every HEDA pallet racking system follows a rigorous 6-stage manufacturing process from CE-certified raw steel to ready-to-install components shipped worldwide.
Mill Certificates
Upright & Beam Profiles
Robotic Weld Lines
Zinc Phosphating
80–100µm Thickness
ISO 9001:2015 QC
Have Questions?
Frequently Asked Questions
Answers to common questions from warehouse managers, distribution center operators, and warehouse project distributors sourcing pallet racking from China.
What is a pallet racking system and what types does HEDA manufacture?+
A pallet racking system is a material handling storage structure designed to hold palletized goods on horizontal beam levels across multiple vertical tiers, allowing forklifts to access stored pallets. HEDA Shelves manufactures six types: Selective Pallet Racking, Drive-In Racking, Double Deep Racking, Narrow Aisle / VNA, Radio Shuttle, and Pallet Live Racking. All are available as OEM/ODM, CE-CPR certified, manufactured with Q235B cold-rolled steel.
What is the maximum beam load capacity of HEDA pallet racking?+
HEDA standard pallet racking beams support up to 4,500 kg per beam level using Q235B cold-rolled steel. For heavy industrial applications — steel coils, automotive components, drum storage — higher capacity configurations are available on request. Frame capacity ranges from 10,000 to 30,000+ kg.
What certifications does HEDA pallet racking carry?+
All HEDA pallet racking systems carry three certifications: CE-CPR (EN 1090), ISO 9001:2015, and RoHS. Full documentation is included with every shipment at no additional charge.
What steel grade is used in HEDA pallet racking and how is it treated?+
HEDA uses Q235B cold-rolled steel (equivalent to ASTM A36 / S235). All components undergo a 4-step surface treatment including acid washing, zinc phosphating, and electrostatic powder coating (80–100µm).
What is the MOQ and lead time for ordering pallet racking from HEDA?+
HEDA offers flexible MOQ — from 1 complete set. Standard production lead time is 15–25 working days after order confirmation.
Does HEDA offer OEM/ODM pallet racking manufacturing?+
Yes — OEM and ODM is a core HEDA capability since 2001. We supply OEM racking to distributors in 120+ countries worldwide. Confidentiality/NDA agreements are available.
Which pallet racking system is best for cold storage warehouses?+
For cold storage (0°C to –30°C), drive-in racking and radio shuttle racking are best. View Cold Storage Solutions →
Does HEDA provide free warehouse layout design?+
Yes — free 3D warehouse layout design is included with every inquiry. We typically deliver a preliminary 3D layout within 24–48 hours. Submit your floor plan →
